The Blustream HD12DB has been designed to convert and down-mix embedded 5.1ch Dolby Audio or DTS Audio within a HDMI signal into a stereo 2ch signal available on HDMI, optical and analogue audio outputs.
The HD12DB features a HDMI loop out to pass the original video and multi-channel embedded audio signal to compatible equipment, with a second HDMI output featuring video scaling of resolutions up to 4K 60Hz 4:4:4 video to various lower video formats.
This provides the perfect cost effective solution for ensuring that 4K UHD video and multi-channel audio can be distributed around a multi-room system where there are a mixture of 2ch and 5.1ch zones with multiple output resolution requirements.
Key features:
- Features an in-built DAC (Digital to Analogue audio Converter) that converts 5.1ch Dolby Audio or DTS Audio to a stereo 2ch signal available on HDMI, optical and analogue audio outputs concurrently
- Supports the following audio input formats: Dolby 5.1, DTS-ES 6.1, DD+5.1, DD+2.0, PCM 5.1, PCM 2.0 *
- Features 1 x HDMI input supporting 4K UHD video (4K 60Hz 4:4:4) that is replicated to 2x HDMI outputs
- HDMI loop out will replicate the HDMI input signal up to 4K 60Hz 4:4:4 and 5.1ch Dolby Audio & DTS Audio
- HDMI output 1 features a video scaler allowing the output resolution to be set to the following formats:
- 3840x2160@60Hz
- 3840x2160@50Hz
- 3840x2160@30Hz
- 3840x2160@25Hz
- 4K DCI@25Hz 4:4:4
- 4K DCI@30Hz 4:4:4
- 4K DCI@50Hz 4:4:4
- 4K DCI@60Hz 4:4:4
- 1920x1080@60Hz
- 1920x1080@50Hz
- 1280x720@60Hz
- 1280x720@50Hz
- 1920x1200@60Hz
- 1680x1050@60Hz
-1024x768@60Hz - HDMI audio breakout to down-mixed analogue L/R audio and down-mixed optical digital outputs concurrently
- HDCP 2.2 compliant with advanced EDID management
*Please note: this product does not support decoding of DTS CD bitstreams. Playback of this format may produce undesirable noise.
Specifications:
- Video Input Connectors: 1 x HDMI Type A, 19-pin, female
- Video Output Connectors: 2 x HDMI Type A, 19-pin, female
- Audio Output Connectors: 1 x Optical (TOSLINK), 2 x RCA analogue Left / Right
- EDID: 4-pin DIP switch
- Resolution: 4-pin DIP switch
- Product Upgrade: 2 x Micro USB female
- Dimensions (W x H x D): 127mm x 23mm x 104mm, without feet
- Operating Temperature: 32°F to 104°F (0°C to 40°C)
- Storage Temperature: -4°F to 140°F (-20°C to 60°C)
- Power Supply: 5V/3A DC
Box Contents:
1 x HD12DB
1 x 5V/3A DC Power Supply
1 x Mounting Kit
4 x Rubber Feet
1 x Quick Reference Guide
