The DA11ABL-WP is a multi-input / output wall plate to convert Bluetooth and analogue audio within a digital Dante® networked audio system.
Key Features:
- Dante® network wall plate interface for Bluetooth and analogue L/R audio inputs, and L/R audio outputs
- Converts 2ch Bluetooth, or un-balanced audio sources to Dante® audio
- Converts 2x Dante® audio channels to un-balanced audio outputs
- Adjustable input sensitivity from +24dBu to -28dBV via control software
- Adjustable output gain from +20dBu to -28 dBV via control software
- Supports: 44.1, 48 & 96kHz sample rates @ 16, 24 or 32 Bit
- Configurable Dante® device latency (supports 1, 2 or 5ms configurable using Dante® Controller)
- Supports AES67 RTP audio transport
- Features Class 0 IEEE 802.3af PoE for powering of product from any PoE switch
- Supports power via 12V DC adapter (supplied) for when network switch does not support PoE
- Magnetic faceplate surround allowing for both UK & EU backbox compatibility
Specifications:
- Audio Input Connectors: 1 x Analogue Left / Right audio (3.5mm stereo jack)
- Audio Output Connectors: 2x Analogue RCA (Left / Right)
- Network Connectors: 1 x PoE Dante® Ethernet Connection (RJ45)
- Bluetooth: Bluetooth V5.0 - SBC / MP3 / AAC / APT-X / APTX-LL / APTX-HD, 44.1K-48KHz 16 / 24Bit
- Configuration Switches: 1 x Push Button (connect / selection)
- Firmware Upgrade: 1 x Micro-USB
- Module Dimensions (W x H x D): 74mm x 74mm x 50mm (without faceplate)
- Faceplate Dimensions (W x H x D): 85mm x 85mm x 5mm
- Cut Out Dimensions (W x H x D): 52mm x 55mm x 38mm
- Mounting hole spacing: UK 60mm CTC, EU 60mm CTC
- Backbox Mounting Depth: 40mm (minimum), 47mm (recommended), UK or EU single gang
- Operating Temperature: 32°F to 104°F (0°C to 40°C)
- Storage Temperature: - 4°F to 140°F (- 20°C to 60°C)
- Power Supply: Class 1 IEEE 802.3af PoE or 12v/1A DC 2-Pin Phoenix connector
Box Contents:
- 1 x DA11ABL-WP
- 1 x Magnetic Faceplate
- 1 x USB Serial UART Programming Cable
- 1 x Quick Reference Guide
