The PRO-IN2H2V input board offers 2x HDMI and 2x VGA sources that can be independently routed to any HDMI/HDBaseT output board and features quick release card module fittings allowing simple installation into the Custom Pro Matrix hub.
Main features:
- Features 2x HDMI and 2x VGA inputs which can be independently routed to video output cards
- Supports up to 4K UHD video (3840 x 2160 @30Hz 4:4:4, 4096 x 2160 @24Hz 4:4:4, and 4K @60Hz 4:2:0)
- Supports all known HDMI audio formats including Dolby TrueHD, Atmos and DTS-HD Master Audio transmission
- Quick release card module fittings allowing simple population of input and output cards in Custom Pro Matrix Hub
- HDCP2.2 Support
Specifications:
Video Input Connectors: 2x HDMI Type A, 19-pin, female, 2x VGA
Card Dimensions (W x H x D): 170mm x 22mm x 182mm
Dimensions Including Connections (W x H x D): 190mm x 22mm x 188mm
Shipping Weight: 0.5kg
Operating Temperature: 32°F to 104°F (0°C to 40°C)
Storage Temperature : -4°F to 140°F (-20°C to 60°C)
