The Blustream DA11AEN-V2 has been designed to encode unbalanced or balanced 2ch analogue audio to Dante® digital signals.
It allows any non-Dante® audio source such as mixing consoles, amplifiers, computers and Blustream Matrix products or distribution products to be connected as a source within a Dante® network.
The DA11AEN-V2 is a plug & play device that is powered using either PoE (Power Over Ethernet) from any PoE network switch or via a local 12V power supply input.
It also supports AES67 RTP audio transport. The inbuilt web interface module can be used for configuration and control of the device.
Key Features:
- Encodes unbalanced or balanced 2ch analogue audio to Dante® digital signals
- Supports 44.1, 48, 88.2 & 96 KHz sample rates @ 16/24/32 Bit
- Configurable Dante® device latency (supports 2-10ms configurable using Dante® Controller)
- Supports AES67 RTP audio transport
- Web interface module for control and configuration of the device
- Features Class 0 802.3af PoE for powering of product from any PoE switch
- Local 12V power supply input for when network switch does not support PoE*
- Dante® is a registered trademark of Audinate Pty Ltd
* PS121PH power supply sold separately
Specifications:
- Audio Input Connectors: 6-pin Phoenix connector (2ch balanced / unbalanced analogue audio)
- Audio Output Connectors: 1 x RJ45, female (100 Mbps Dante® network)
- Casing Dimensions (L x W x H): 120mm x 47mm x 26mm
- Operating Temperature: 32°F to 104°F (0°C to 40°C)
- Storage Temperature: - 4°F to 140°F (- 20°C to 60°C)
- Power Supply: Class 0 IEEE 802.3af PoE PD or 12V/1A DC 2-PIN Phoenix connector
Box Contents:
1 x DA11AEN-V2
1 x Quick Reference Guide
