The Kordz ONE Series CAT6a cable has been designed and engineered to provide a cable system infrastructure with assurance for advanced applications that demand more bandwidth and greater performance. This makes for a more robust and complex system at Gigabit speed and full duplex transmissions. This premium shielded twisted pair (F/UTP) cable with grounding, provides industry-leading protection inherent in complex systems from external cable noise sources, also known as alien crosstalk or EMI (electromagnetic interference).The new smaller and more compact Rapid-EZ-Reel packaging allows the easy flow of cable
from the box, whilst keeping the cable from twisting and curling, greatly minimising snags during installation therefore saving precious
time.
Key Selling Features:
• Suitable for 10BASE-T, 100BASE-TX, 1000BASE-T/1000BASE-TX (Gigabit) & 10GBaseT, PoE & PoE+
• F/UTP Ethernet CAT6a
• Four Twisted Pairs 23 AWG Solid Copper Conductors
• PVC Separator Reduces Crosstalk Between Pairs
• Mylar laminated aluminium tape shielding with a 26AWG drain wire
• Suitable for IDC Terminations
• Supplied in the durable Rapid-EZ-Reel packaging – 152.5m (500ft)
• Metre Marked
• Exceeds ANSI/TIA 568-C.2 and ISO/IEC 61156-5 standards
• CPR Declared Performance: ONE-CAT6A: Dca-s1, d2, a1 (EN50575:2014+A1:2016)
Technical Specifications:
• Conductor: Solid OFC annealed bare copper wire 0.561 +0/-0.015mm [23AWG]
• Insulation: Orange & Brown Pairs - Polyethylene (PE), 1.12+/-0.05 mm
• Blue & Green Pairs - Foam PE, 0.97 +/-0.05 mm
• Twisting: 4 twisted pairs, 2 cores to each pair
• Twisted Pair Colour Code: 1 - white-blue/blue, 2 - white-orange/orange, 3 - white-green/green, 4 - white-brown/brown
• Cable Lay-Up: 4 pairs with different pitches, non-metallic cross separator (spine)
• Shielding: Drain wire [26AWG], Mylar tape laminated with aluminium foil as a shield
• Outer Diameter: 7.4 +/-0.3 m
• Bend Radius: without load ≥ 29.6mm /1.16”, with load ≥ 59.2mm /2.33”
• Temperature Range: During Operation: -20°C to 60ºC; During Installation: 0°C to 50ºC
• DC Resistance: ≤ 9.38Ω / 100m at 20ºC
• Resistance Unbalance: ≤ 2% at 20ºC
• Insulation Resistance (500V): ≥ 5000MΩ / km at 20ºC
• Mutual Capacitance: ≤ 5.1 nf / 100m at 1khz
• Capacitance Unbalance (pair to ground): ≤ 160 pf / 100m at 1khz
• Nominal Velocity of Propagation: nom. 67% c
• Test Voltage: 1kV DC / 1 min
