The INSTALL® CAT6 PE (Box), a product that embodies superior design and excellent performance, tailored perfectly to meet the diverse installation needs of the consumer.
Key Selling Features:
• Incorporation of UTP CAT6 4 Pair technology providing an impressive 250MHz data rate.
• Solid Conductor CAT6 equips installers with a product compliant with both ISO/IEC11801, TIA/EIA568C.2 standards.
• Capable of 1000Base-T data rate, ensuring high-speed, reliable data transmission.
• Packaged neatly in a 305m box for easy installation.
• The product boasts superior performance even under tough conditions, thanks to its maximum transmission rate of 1000Mbps.
Technical Specifications:
• Solid Bare Copper Wire conductor of size 23AWG (1/0.57 - ±0.005) ensuring robust and seamless performance.
• 4 pairs of wires insulated with HDPE Ø 0.98mm (±0.02mm) material.
• Outer sheath made from Polyethylene for added durability.
• UV resistant to ISO4892-3.
• Weighs approximately 58kg/km.
• Operating temperature range: -40°C - +75°C.
• Installation temperature range: -30°C - +65°C.
• Certified with EN50575 CPR Class: Fca for safety compliance.
• Conductor DC Resistance of 93.8 [Ω/km].
• Conductor resistance unbalance maximum of 5.0%.
• Characteristic Impedance 100Ω (±15)
• Velocity ratio of 72%.
• Withstands Voltage of 600V and a Spark Test of 2.5kV.
The INSTALL® CAT6 PE Box is a 305m, robust, high-fidelity conductor for seamless, high-speed data transmission, perfect for your installation needs.
