An excellent cable for the elite systems installer.
- CLASS A+ COMPLIANT
- TRI SCREENED
- SOLID FOAM DIELECTRIC
- SOLID COPPER CONDUCTOR
- CAI APPROVED
- ROHS COMPLIANT
- LSNH TO: IEC 61034-1, IEC 60332-1, IEC 60332-3 CAT C, IEC 754-1
Physical Characteristics:-
Conductor: CU 1.0 +/- 0.02mm
Dialectric Thickness: 1.81mm
Dialectric Material: Gas injected physical foam
Dialectric Diameter: 4.65 +/- 0.15MM
Dialectric Colour: Natural
1st Foil: CU 115%
Braid: CU 0.12+/-0.008x 16x5
Braid coverage: 55%
2nd Foil: AL-PET 115%
Sheath thickness: 0.66mm
Sheath: LSNH
Overall Diameter: 6.70 +/- 0.15
Packing: 250m wooden drums
CAI Approval number: CAI 0068 A
Electrical Characteristics:-
Rated Voltage: 30V
Capacitance: <56 pF/m
Velocity Ratio: 82.5%
Impedance: 75
Attenuation at 20 Deg C db/100m +/- 5%
10 MHz: 1.8
50 Mhz: 4.2
100 Mhz: 5.9
230 Mhz: 9.1
470 Mhz: 13.3
860 Mhz: 18.3
1000 Mhz: 19.9
1750 Mhz: 27.0
2150 Mhz: 30.3
Screening Effectiveness (dB)
30-470 MHz: >75
470 – 1000 MHz: >75
1000 – 2150 MHz: >65
