Type 120 Ku-Band Receive Only Antenna System
The Skyware Global 1.2 m Type 120 Offset Antenna is a rugged commercial grade product suitable for the most demanding applications. The reflector is thermoset-molded for strength and surface accuracy. Molded into the rear of the reflector is a network of support ribs which not only strengthens the antenna, but also helps to sustain its critical parabolic shape.
Rugged Reflector Mount
The Type 120 Az/EI mount is constructed from heavy-gauge steel to provide a rigid support to the reflector. The Az/EI mount secures the antenna to either a 60 mm 12.38"] or 73-76 mm 12.88"-3.00") 0.D. mast and prevents slippage in high winds.
Corrosion Proof Antenna Backstructure
A specially formulated powder paint process offers excellent protection from weather-related corrosion.
Key Features
- All materials comply with EU directive No. 2002/95/EC (RoHS)
- One-piece thermoset-molded offset reflector
- Single bolt fine elevation adjustment
- Galvanized 19 mm 1.75"] O.D. feed support legs
- Factory pre-assembled Az/EI mount
- Plated hardware for maximum corrosion resistance
- Available with a wide variety of feeds
RF Performance
Effective Aperture
1.2M (48 in)
Operating Frequency
3.40 - 4.80 GHz
Polarization
Linear (circular optional)
Gain @ 11.95 GHz
32.0 dBi
3 dB Beamwidth
4.4˚
Antenna Noise Temperature @30° El
32°K
VSWR
1.3:1
Cross-Polarization Discrimination (Linear)
30 dB on Axis
Feed Interface
CPR229 Flat Flange
Mechanical Performance
Reflector Material
Glass Fiber Reinforced Polyester
Antenna Optics
One-Piece Offset Feed Prime Focus
Mount Type
Elevation over Azimuth
Elevation Adjustment Range
10˚ - 70˚ Continuous Fine Adjustment
Azimuth Adjustment Range
360˚ Continuous
Mast Pipe Interface
73 - 76 mm (2.88 - 3.00 in) Diameter
Wind Loading
Operational
Survival
80 km/h (50 mph)
200 km/h (125 mph)
Temperature
-50˚C to 80˚C
Humidity
0 to 100% (Condensing)
Atmosphere
Standard Hardware Meets 500 Hour Salt Spray Test Requirements (ASTM B-117)
Solar Radiation
360 BTU/h/ft²
